Wallbox Pulsar Pro

The ultimate EV charger for shared spaces, made for Pros like you.

Built for Businesses and EV drivers alike, Pulsar Pro is the new shared charging solution designed to fit perfectly with condominiums, workplaces and fleets. It´s a reliable, accessible charger for users and an easy-to-manage, cost-effective solution for charge point operators and installers.

This charger is on EECA’s (the Energy Efficiency and Conservation Authority) approved list of smart residential/commercial EV chargers.

Make An Enquiry

Technical Specifications

General Specifications


White & Grey

Charging Mode

Mode 3


198mm x 201mm x 99mm(without cable)


1.3kg (without cable)

Cable Length

5m / 7m

Operating temperature

-30°C to +50°C

Storage temperature

-40°C to +70°C


Tamper detection, secure update, secure boot, secure storage & encrypted communicationsC

Charging power

7,4kW / 11kW[1] / 22kW

Rated Voltage AC ± 10%

230V / 400V

Rated Current

32A (1P) / 32A (3P)

Connector Type(IEC 62196)

Type 2

Cable Width

up to 13mm2

Configurable Current

from 6A to rated current

User Interface & Communications


4G, WiFi, Bluetooth

User Interface

myWallbox app & portal

Charger Status Information

Halo RGB LED, myWallbox App & Portal

User Identification

RFID, myWallbox App & Portal

External communication interface

OCPP, partner API and SDK

Included Features

Schedules, Statistics, lock/unlock/autolock, charger remote control, User Management, Pay per Month, Pay per charge, Power Sharing

Optional features

Power Boost, Dynamic Power Sharing, Eco-Smart, External MID

HW ready features


What’s in it for your business?

  • Pre-configured 4G provides out-of-the-box installation, reducing commissioning time and potential errors.
  • 3rd-party 4G & OCPP factory configuration available as an option to reduce installation time.
  • Backplate design to make installation easier than ever.
  • 4G connectivity ensuresremote software updates.
  • Enhanced Security prevents unauthorized manipulation, physical damage and cyber- attacks.
  • Charging cable can be easily replaced in case of damage.
  • Dynamic Power Sharing up to 100 chargers translates into more energy efficiency and lower costs.
  • Internal meter with less than 2% error improves accuracy of energy transfers.*
  • Integrated PEN fault protection eliminates the need for an earthing rod.**
  • myWallbox business enables charger management, payments, user access, reporting and more.
  • OCPP compatible to integrate into any backend.
  • Partner API available for custom integrations.*

Maximize sustainability and savings with our energy management features

  • ECO-SMART Solar EV Charging
    Use the surplus energy from a building’s solar panels to avoid high grid energy prices. Charge with 100% solar energy or a mix of solar and grid energy.

  • POWER BOOST Dynamic Load Balancing for Single EVs
    Charge at the highest speed possible, depending on the building’s real-time energy use, without having to upgrade the electrical infrastructure.

  • DYNAMIC POWER SHARING Load Balancing for Multiple Vehicles
    Scale your charging infrastructure without expensive electrical retrofits. Intelligently distribute energy now up to 100 chargers.
